Abus D10NP 30/45 Cylinder Lock Insert Anti-Picking System Class 5 Nickel Pearl 5 Keys

Product Overview

Abus D10NP 30/45 is a high-security cylinder lock insert, designed for use with mortise locks in residential and commercial buildings requiring advanced anti-burglary protection. Certified to PN-EN 1303:2007 and rated at class 5.2 for key security with 10 pins and up to 100,000 key combinations, it offers a durability of at least 50,000 cycles and corrosion resistance at class C for operation from -20°C to +80°C. The product features emergency function, allowing operation even when a key is inserted from the opposite side.

The standout feature of this model is its patented anti-picking system, employing specially dimensioned pins and driver pins, providing verified effectiveness against manipulation and break-in attempts. This minimizes security risk and supports compliance with demanding access control requirements. Particularly suited for bulk procurement by facilities managers, security integrators, and OEM door manufacturers in new construction or retrofit security upgrades.

Key Features

• Patented anti-picking system ? unique pin and driver pin profiles proven to resist manipulation


• Pre-snap break protection ? cylinder remains secure even if forced breakage occurs


• Key security class 5 ? 10 pins, 100,000 combinations for advanced access control


• Emergency function ? cylinder can be operated from either side, enhancing user safety


• Corrosion resistance class C ? operational reliability from -20°C to +80°C


• Attack resistance class 2 ? withstands minimum 5/10 minutes and 40 impact hits


• Long lifespan ? minimum 50,000 cycles durability for high-traffic applications

Technical Specifications

• Cylinder Size: 30/45 mm


• Certification: PN-EN 1303:2007 1 5 0 0 0 C 5 2 C


• Durability: ?50,000 cycles


• Key Security Class: 5 (10 pins, 100,000 combinations)


• Attack Resistance Class: 2


• Corrosion Resistance Class: C


• Operating Temperature: -20°C to +80°C


• Emergency Function: Yes


• Material: Body - brass; pins and driver pins - bronze and hardened steel; follower - steel; springs - stainless steel


• Finish: Nickel pearl


• Included Keys: 5 (drilled keys)

Applications

Used in mortise locks for residential blocks, commercial properties, institutional facilities, and new-build or retrofit security projects. Suitable for fire-rated doors, high-traffic entry doors, and installations where resistance to picking, breaking, and corrosion is essential. Commonly specified by OEM door manufacturers, facility managers, and security integrators seeking certified hardware for advanced access control.

Packaging & Shipping

Sealed export packaging in tamper-evident box. Each unit includes the cylinder, 5 drilled keys, security code card, mounting screw, and installation guide. Bulk shipping for large orders available upon request.
