Abus Pfaffenhain Standard 30g/35 Cylinder Lock Nickel Pearl Emergency Clutch Class 6 EN 1303

Product Overview

The Abus Pfaffenhain Standard 30g/35 cylinder lock with nickel pearl finish and knob is engineered for high-security door installations in commercial and residential settings. Certified to PN-EN 1303:2015-07 with classification 1 6 0 B 0 C 6 B, this lock meets stringent fire and smoke door requirements and offers the highest resistance to corrosion and temperature within class C. It is supplied with five cut keys, coding card, and mounting screw for straightforward integration.

A key differentiator of this cylinder is the emergency clutch function, allowing operation even when keys are inserted from both sides. This eliminates user access blockages, particularly important in shared or multi-tenant buildings with master key systems. Facility managers and bulk procurement specialists benefit from its master key compatibility, making it ideal for large residential complexes, hotels, and institutional installations.

Key Features

• Emergency clutch function ? enables cylinder rotation with keys inserted on both sides for uninterrupted access


• Certified to PN-EN 1303:2015-07 ? fully compliant with European security, fire, and smoke door standards


• Class 6 key security ? 6 tumblers with 100,000 combinations for maximum protection against unauthorized key duplication


• Class B attack resistance ? withstands mechanical attack and drilling for up to 5/10 minutes


• Highest corrosion and temperature resistance ? class C rating for durable operation in demanding environments


• Multiple centering asymmetric profiles ? anti-pick design improves resistance to lock picking attempts


• Hardened steel first and third pin ? additional protection against core drilling attacks

Technical Specifications

• Length: 30 mm/35 mm (asymmetrical)


• Finish: Nickel pearl


• Security Classification: PN-EN 1303:2015-07, class 1 6 0 B 0 C 6 B


• Key Security: Class 6 (6 tumblers, 100,000 combinations)


• Attack Resistance: Class B (5/10 min. drill and mechanical attack resistance)


• Corrosion Resistance: Class C


• Fire and Smoke Door Approval: Yes


• Core Diameter: 14 mm


• Number of Keys Included: 5


• Key Material: New silver (paracentric profile)


• Additional Protection: Hardened steel pins (first and third), anti-drill housing

Applications

Commonly installed in commercial and residential buildings such as hotels, apartments, offices, and public institutions. Approved for use in fire-rated and smoke-control doors, and highly suitable for master key system deployments. Optimal for settings requiring advanced security, high durability, and strict access control protocols, including bulk procurement projects and facility management.

Packaging & Shipping

Cylinder lock supplied in tamper-proof, sealed packaging with 5 cut keys, coding card, mounting screw, and installation accessories. Designed to ensure integrity and security during transport.
