CES PSM 30/30 Cylinder Lock EN 1303 Class 6.D Nickel Anti-Drill 3 Patented Keys

Product Overview

CES PSM 30/30 nickel-plated cylinder lock is engineered for controlled access in residential and commercial buildings where certified security standards are required. Featuring break-in resistance with EN 1303:2015 burglary protection class 6.D and adhering to DIN 18252, it offers robust defense against manipulation and unauthorized entry. The cylinder includes three patented, machine-cut keys and a key duplication card for secure, traceable key reproduction.

The standout feature of this SKU is its anti-drill and anti-pick construction, with hardened steel pins and supplemental metal inserts at the cylinder front, providing enhanced resistance against physical attack compared to standard cylinders. This eliminates procurement risk for facility managers and security installers seeking certified, tamper-resistant locking solutions for high-risk areas. Particularly suited for bulk procurement projects in multi-family housing, corporate offices, and access-controlled institutional environments.

Key Features

• EN 1303:2015 class 6.D ? certified burglary protection for high-security applications


• Anti-drill and anti-pick ? hardened steel pins and special metal inserts defend against forced entry and manipulation


• Patented key profile ? prevents unauthorized key copying, supported by a protected duplication card


• 6 spring-loaded driver pins ? improves lock complexity and resistance to picking


• Nickel-plated brass key ? 3.5 mm thick, corrosion-resistant CDA alloy for durability


• DIN 18252 compliance ? ensures compatibility with standard lock hardware in EU markets


• Modular design option ? can be integrated into CES electronic access systems

Technical Specifications

• Cylinder Length: 30/30 mm


• Material: Nickel-plated brass


• Number of Pins: 6 (spring-loaded), 1 in body, remaining in barrel


• Key Thickness: 3.5 mm


• Included Keys: 3 (machine-cut, patented profile)


• Burglary Protection Class: 6.D (EN 1303:2015)


• Certification: EN 1303


• Certification: DIN 18252


• Patent Protection: Yes (key profile)

Applications

Used for controlled-access entry points and interior doors in residential complexes, office buildings, and institutional facilities. Suitable for installations where high burglary resistance and strict key management are mandated, including multi-tenant environments, corporate security, and upgrade projects requiring certified European cylinder locks. Compatible with standard DIN mortise locks and can be used in modular or electronic access control systems.

Packaging & Shipping

Tamper-evident sealed box packaging, with cylinder, three patented keys, key duplication card, and installation accessories included. Packaging ensures product integrity and security until installation.
