LOB HEKTOR Cylinder Set 40g/40+40/40 Nickel Satin EN 1303:2007 Class 4 Keyed Alike

Product Overview

The LOB Hektor Cylinder Set 40g/40+40/40 Nickel Satin is a pair of anti-burglary euro-profile cylinder locks, comprising a knob cylinder and a double-sided cylinder keyed alike. Designed for commercial and multi-unit residential applications, these cylinders are suitable for installation in fire-rated door assemblies and environments requiring high protection against break-ins and environmental stress. Certified by the Institute of Precision Mechanics in Warsaw to PN: EN 1303:2007, the set achieves the highest available grade for durability and corrosion resistance.

This specific set features class 4 security with a tested key profile providing at least 30,000 key combinations, minimizing the risk of unauthorized duplication in large building complexes. Its compliance with the most stringent classification for operational cycles and burglary resistance ensures peace of mind for facility managers and procurement in new developments or retrofits. Especially suited for bulk procurement by facility operators, locksmiths, and project contractors specifying fire-protection and high-security door hardware.

Key Features

• High burglary resistance ? class B per KT/402/IMP/2009 with anti-drill and anti-pick features


• Durability class 6 ? rated for minimum 100,000 operating cycles (EN 1303:2007)


• High key security ? at least 30,000 unique key combinations, 5-pin profile


• Corrosion resistance class C ? operates from -20°C to +80°C, suitable for demanding environments


• Keyed alike system ? knob and double-sided cylinders operated by the same key for convenience


• Fire door approved ? certified for installation in fire-rated door assemblies


• Comes with 6 nickel-plated, five-cut keys and code card ? for secure duplication

Technical Specifications

• Cylinder Type: Double-sided and knob cylinder set


• Lock Classification: 16010C42 B


• Length: 40/40 mm (cylinder), 40g/40 mm (knob cylinder)


• Material Finish: Nickel satin


• Operating Temperature: -20°C to +80°C


• Durability: Class 6 (?100,000 cycles)


• Corrosion Resistance: Class C


• Key Security: Class 4 (?30,000 combinations)


• Burglar Resistance: Class B (KT/402/IMP/2009)


• Torque Resistance: 15 Nm


• Key Profile: 5-pin, scored key


• Certification: PN: EN 1303:2007


• Fire Door Suitability: Yes (certified by IMP)

Applications

Suitable for use in commercial, institutional, and high-end residential buildings, especially where doors require fire-rated and high-security locking solutions. Recommended for office blocks, hotels, schools, healthcare facilities, and multi-unit dwellings. Compatible with new builds and modernization projects where certified and standardized cylinder sizes are required. Particularly effective for unified keying and restricted key copy requirements in facility management.

Packaging & Shipping

Each set is supplied in a sealed retail box containing one double-sided cylinder, one cylinder with adjustable knob, six nickel-plated scored keys, a mounting screw, and a key code card for controlled duplication. Packaging is tamper-evident and suitable for export or bulk shipment.
